Voltage

DC12V-26.2V

Power   Consumption

Dynamic 10W

Technical   Parameters

Roll   Angle

-45°～ +45°

Pitch   Angle

-45°～ +120°

Yaw   Angle

-290°～ +290°

Pitch   and Roll Jitter Angle

±0.02°

Horizontal   Jitter Angle

±0.03°

Adjustable   Gimbal Speed

Adaptive Speed Control (Visible Light Camera)

One-Click   Restore

One-click restore to the initial position

Visible Light Camera

SENSOR

1/2.8-inch 2MP Wide Dynamic Range CMOS Sensor

Zoom

30× HD optical zoom lens, f=4.5±10%～135±10%mm

Focus

Focus in real time, ＜1 s

Video   Output

Ethernet (RTSP) output , Local TF card 1080p   recording

Field   of Vision(FOV)

D : WIDE 67.8º±5% TELE 2.77º±5%

H : WIDE 59.8º±5% TELE 2.34º±5%

V : WIDE 40.5º±5% TELE 1.48º±5%

Video   mode

1080P 30fps

Laser   Illuminator

Laser   Type

850±10nm

Laser   Safety Class

Class  3B

Effective   Range

≥800m

Beam   Angle

Narrow angle: 2.0° @ ≥800m range (28m spot)

Wide angle: 70° @ ≥80m range (112m spot)

Storage   Capacity

128G TF card; class6 and above;

Control   mode

IP, UART,SBUS (PWM optional)

Control   Interface

TTL

Gimbal   Size

110mm×164.5mm×159mm

Working   Condition

-10℃ to +55℃ / 20% to 80% RH

Storage   Environment

-20℃ to +60℃ / 20% to 95% RH

Weight

1066±10g

1

8PIN

Power Interface

GND

GND

2

Power Interface

5V

+5V Output

3

Communication   Protocol

RXD4

UART   receiving

4

Communication Protocol

TXD4

UART   sending

5

Communication   Protocol

DB-

Network Interface

6

Communication Protocol

DB+

Network Interface

7

Communication   Protocol

DA-

Network Interface

8

Communication Protocol

DA+

Network Interface
